Wearable



SKU

Description

N0D71S61

CHIP LED, 0803 (2008) 0.60t, Infrared (IR)/Red, 930/650-950/670nm, 0.12W, 20/20mA, 2.80/3.20mW/sr (typ.), 1.3/2.1V, 120/120°, for Wearable, Max.4000pcs/reel

Login

N0D60S84

CHIP LED, 0803 (2008) 0.75t, Infrared (IR)/Red, 931/653-950/658nm, 0.12W, 20/20mA, 9/11mW/3.0/3.7mW/sr (typ.), 1.4/2.0V, 60/60°, for Wearable, Min.100pcs/reel

Login

N0M68S24

CHIP LED, 0808 (2020) 0.60t, Infrared (IR)/Red/Green, 931/653/523-950/658/542nm, 0.18W, 20/20/20mA, 9/16/12mW/3.4/5.3/4.2mW/sr (typ.), 1.2/1.8/2.6V, 120°, for Wearable, Min.100pcs/reel

Login

N0P60S85

CHIP LED, 0808 (2020) 0.75t Photo-Diode, PD, Peak Sensitivity-900nm, 120°, Response Range: 400~1100nm, Radiant Sensitive Area: 1.49mm^2, Active Chip Area: 1.22x1.22mm, Capacitance: 13.4pF, Min.100pcs/reel

Login

N0M61S45ICT

LED EMC SMD, 5050 ICT 1.00t (6-pins), Red/Green/Blue, 615/520/460-630/530/475nm, ---W, 12mA, 320/700/150mcd (typ.), 5V, 120°, with IC, with Touch Sensor, 24-bit, Rate of Data Signal: 800KHz, Data Transmission by DATA+TOUCH, RGB Binning, High Speed Mode, Brightness Adjustment, Feedback Mode, PWM Refresh Control, Support Parallel Connection, Signal Reshaping, White Calibration Function, Max.1000pcs/reel

Login

N0M61S47ICT

LED EMC SMD, 5050 ICT 1.00t (6-pins), Sky White/Red/Green/Blue, 6500K/615/520/460-55000K/630/530/475nm, ---W, 12mA, 580/320/700/150mcd (typ.), 5V, 120°, WRGB, with IC, with Touch Sensor, 32-bit, Rate of Data Signal: 800KHz, Data Transmission by DATA+TOUCH, WRGB Binning, High Speed Mode, Signal Reshaping, White Calibration Function, Max.1000pcs/reel

Login

N0M62S55ICT

LED EMC SMD, 5050 ICT 1.00t (8-pins), Red/Green/Blue, 615/520/460-630/530/475nm, ---W, 12mA, 320/700/150mcd (typ.), 5V, 120°, with IC, with Touch Sensor (Individual Power), 24-bit, Rate of Data Signal: 800KHz, Data Transmission by DATA+TOUCH, RGB Binning, High Speed Mode, Brightness Adjustment, Sleep Mode, Feedback Mode, PWM Refresh Control, Support Parallel Connection, Signal Reshaping, White Calibration Function, Max.1000pcs/reel

Login
